Wichita State Formula SAE

Established in 2005, Shocker Racing has been designing, manufacturing, testing, and racing collegiate level formula cars. This student organization is open to any Wichita State student. In this team, you will get the chance to apply what you learn in the classroom to the real world.




What is Formula SAE?

Formula SAE is a worldwide engineering competition sponsored by the Society of Automotive Engineers (SAE). Over 140 universities compete with an open-wheel style racecar including other countries such as Japan, Germany, and Brazil in competitions held in Michigan and Nebraska and other locations. Formula SAE greatly assists in preparing students for real world experiences, problem solving, management, and communication.

The concept behind Formula SAE is that a fictional manufacturing company has contracted a student design team to develop a small Formula-style race car. The prototype race car is to be evaluated for its potential as a production item. The target marketing group for the race car is the non-professional weekend autocross racer. Each student team designs, builds and tests a prototype based on a series of rules, whose purpose is both ensuring on-track safety (the cars are driven by the students themselves) and promoting clever problem solving. The prototype race car is judged in a number of different events.

2024 Formula SAE Rules

WSU Formula SAE Bylaws




Event Point Distribution:

Pie chart showing a visual representation of Event Point Distribution. The information is verbally presented in the Events Explained section below.



Events Explained:

Acceleration Event (7%):

In four 75-meter runs, the fastest time is recorded to test the acceleration.

Skid-Pad Event (5%):

The cornering capability of the racecar is evaluated by driving the car in a figure-eight formation as fast as possible without knocking over any of the cones that outline the course.

Autocross Event (15%):

Drivers must maneuver the car through the tight turns and slaloms of a one-lap course. Any cones knocked over count as penalties. Each team is granted four attempts, of which the fastest lap time is recorded.

Endurance Event (30%):

This intense 22-kilometer closed-course race tests the limits of the car and requires a driver change in the middle. Cars are not allowed to leak any fluids, and only cars that cross the finish line can score any points. Also the fuel economy is calculated and compared with the other vehicles.

Design Event (15%):

This event rates the quality of engineering design used in the car development of the racecar. Judges evaluate the team's innovative ideas as well as test the reasoning and theory behind the design by questioning the students. During the event, the vehicle's test data and analysis are also scrutinized.

Presentation Event (8%):

Students deliver a quality technical sales presentation that persuades the fictional manufacturer to put the car into production. The judges are to be assumed to be executives of a corporation.

Cost & Manufacturing Analysis Event (10%):

Teams must submit a report detailing the total prototype cost of the vehicle and capital expenditures (plants, machinery, and tools) for a limited production run by a hypothetical manufacturing firm. There is no maximum cost.


In addition to these events, various sponsors of the competition provide awards for superior design accomplishments. For example, best use of E-85 ethanol fuel, innovative use of electronics, recyclability, crash worthiness, and analytical approach to design are some of the awards available. At the beginning of the competition, the vehicle is checked for rule compliance during the Technical Inspection. Its braking ability, rollover stability and noise levels are checked before the vehicle is allowed to compete in the dynamic events (Skidpad, Autocross, Acceleration, Endurance and Fuel Economy).

Formula SAE encompasses all aspects of a business including research, design, manufacturing, testing, developing, marketing, management, and fund raising. Formula SAE takes students out of the class room and puts them in the real world.


Note: Some of the above information was obtained from the Formula SAE Wiki.
